Description
The most popular compact 2G model for basic tracking
2G 4G M1
Additional information
| Physical specification | Dimensions: 79 x 43 x 12 mm (L x W x H) Weight: 54 g |
|---|---|
| Module | Name: Teltonika TM2500 Technology: GSM/GPRS/GNSS/BLUETOOTH |
| GNSS | GNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS Receiver: 33 tracking channel Tracking sensitivity: -165 dBM Position Accuracy: < 2.5 m CEP Velocity Accuracy < 0.1 m/s (within +/- 15% error) Hot start: < 1 s Warm start: < 25 s Cold start: < 35 s |
| Cellular | Technology: GSM 2G bands: Quad-band 850 / 900 / 1800 / 1900 MHz Data transfer: GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Data support: SMS (text/data) |
| Power | Input voltage range: 6–30 V DC with overvoltage protection Internal Back-up battery: 170 mAh Li-Ion battery, 3.7 V (0.63 Wh) Internal fuse: 3A, 125V Power consumption: At 12V < 2 mA (Ultra Deep Sleep) At 12V < 4 mA (Deep Sleep) At 12V < 5 mA (Online Sleep) At 12V < 6 mA (GPS Sleep) At 12V < 25 mA (nominal) |
| Bluetooth® | Specification: 4.0 + LE Supported peripherals: Temperature and Humidity sensor, Headset, OBDII dongle, |
| Operating environment | Operating temperature (with battery): -20 °C to +40 °C Operating temperature (without battery): -40 °C to +85 °C Storage temperature (without battery): -40 °C to +85 °C Operating humidity: 5% to 95% non-condensing Ingress Protection Rating: IP54 Battery charge temperature: 0 °C to +45 °C Battery discharge temperature: -20 °C to +60 °C Battery storage temperature: -20 °C to +45 °C for 1 month -20 °C to +35 °C for 6 months |
| Interface | Digital Inputs: 1 Digital Outputs: 1 Analog Inputs: 1 GNSS antenna: Internal High Gain Cellular antenna: Internal GSM High Gain USB: 2.0 Micro-USB LED indication: 2 status LED lights SIM: Micro-SIM Memory: 128MB internal flash memory |
| Features | Sensors: Accelerometer Scenarios: Green Driving, Over Speeding detection, Jamming detection, GNSS Sleep modes: GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep Configuration and firmware update: FOTA WEB, FOTA, Teltonika Configurator SMS: Configuration, Events, DOUT control, Debug GPRS commands: Configuration, DOUT control, Debug Time Synchronization: GNSS, NITZ, NTP Fuel monitoring: LLS (Analog), OBDII dongle Ignition detection: Digital Input 1, Accelerometer, External Power Voltage, Engine |
| Certification & approvals | Regulatory |
